Scissor Lift

Wheel & Rubber Crawler (ENCL/ENTL Series)

ENCL045S-3

AIRMAN diesel engine air compressor has more than 80 years experience with Japanese customers.

Our flexible and high durability compressor can be usuful for long time in Civil Construction/Foundation/ hill slope reinforcement/Water well drilling/Quarry and Mining/Shipyard (Sand blasting & Spraying)/ Oil & Gas (sand blasting, spraying, pipe leak test).

Please send your inquiry to us, our distributor will recommend you the suitable model.

Specification

MODEL ENCL045S-3
*WORK PLATFORM
Max load (kg)200
Max. height above ground (mm[inch])4500[177.2]
Min.height Above ground (mm[inch])890[35.0]
Internal Dimensions when extended)×w×h (mm[inch])1200(1750)×645×950 [47.2(68.9)×25.4×37.4]
Extension platform sliding capacity (mm[inch])550[217]
*SCISSORS LIFT
Type4-stage X-type pantographs with one end fixed
Lifting speed (up / down) (sec)18/26
*TRAVEL MOTOR
DrivingDC Motor
Travel speed (high/low) (km/hr)0~2.0 / 0~0.8
Gradeability (°)14
Min. turning radius (mm[inch])Spot Turn
TravelingRubber crawler type
*POWER SUPPLY
Input power supply(v)AC 100~110 / 200~240
Battery voltage(v)DC 24
Battery capacity (5 hour rate)(v)100
BatteryEB100×2
*DIMENSION & WEIGHT
L×W×H (mm[inch])1390×780×1840 [54.7×30.7×72.4]
Machine weight (kg)650

Specifications are subject to change without notice. Please consult your Hokuetsu dealer for details.
